TownSteel - E-Genius 4000 - Interconnected Electronic Touch Keypad Lock - Storeroom - RFID - 5 1/2" - Quest Lever - Optional Handing - Matte Black - Grade 1

The e-Genius 4000 is the only keyless double lock providing the ability to lock and unlock an interconnected dead-latch and deadbolt with a single lift of the lever from inside and outside of your home. Access your home with keyless freedom and convenience using a highly responsive, 12-key illuminated touch and fingerprint resistant keypad programmable with up to 400 user user codes interchangeable with RFID keycards/stickers. Mechanical key override lock is available as an extra back-up.



• Latchbolt can always be locked so that when shutting the door, it is automatically locked
• Extended deadbolt
• Left Hand, Right Hand
• Quest Lever
• Including 2 RFID Key Cards and 2 RFID stickers



Function	Storeroom
Door Thickness:	1-3/4”
Backset	2-3/8″ – 2-3/4″ adjustable
Lock Body	5.5"
Trim	Clutched
Latch bolt:	1/2“ throw stainless steel deadlocking
Faceplate	1" x 2-1/4"
Deadbolt Strike	1-1/8″ x 2-3/4″ radius corners with security underplate
Key Override	Yes
Cylinder	6 pin Schlage C keyway, standard
Power Supply	4 AA Alkaline batteries - No Hard wiring
Battery Life	Up to 1 year
Finish	626 - US26D - Satin Chrome, 622 - US19 - Flat Black Coated
Handing	Left Handed, Right Handed
Certifications	ANSI/BHMA A156.2 -- A156.2-2011 Grade 1 certified UL/ULC -- UL 10C 3-hour rated BAA -- Meets guidelines of the Buy American Act ADA --- Meets requirements of the Americans with Disabilities Act RoHS -- Meets requirements of EU RoHS Directive 2002/95/EC
Manufacturer Warranty	2-year limited for electronic 5-year limited for finish 10-year limited for mechanical





Downloads:

• Installation Instructions
• Door Template
