TELL - LC2681 - Standard Duty Cylindrical Leverset - Cortland Lever - Entry - IC Core - Grade 2 - Oil Rubbed Bronze

The LC2600 Series Cortland Lever is a grade 2 cylindrical, standard-duty lever in a satin stainless steel finish that can be used for entry, storeroom, privacy, and/or passage. These levers can be used in new construction or replacement hardware, fitting a standard 161 door prep.

Specifications:

Performance	Grade 2 standard duty 400,00 cycles
Compliance	UL/ULC Listed for 3-hour fire door, American Disabilities Act (ADA) ANSI A117.1 ANSI A156.2, Series 400
Chassis	Cylindrical Steel - corrosion resistance
Handing	Non handed
Style	Cortland
Latch	2-3/4" backset
Strike	ASA strike 1-1/4" x 4-7/8"
Rose	3-1/4" Diameter
Door Range	1-3/8" - 2"
Warranty	Manufacturer's Limited Lifetime
Keys Included	Yes, 2 Nickel silver per lock cylinder
Cylinder	SCC Standard, C keyway, 6-Pin Solid Brass, Keyed Different
Door Prep	1" Diameter for latchbolt, Fits standard 161 door prep
Finish	US10B Oil Rubbed Bronze
