Schlage - F-Series - Elan Lever Set - Passage - Round Rose - Bright Brass - Grade 2

The Schlage F10-ELA series of residential locks very easily stand up to constant use and abuse while keeping people and property safe. Our F-series locks have an ANSI/BHMA 156.2 grade 2 rating and come in a choice of styles and finishes that fit your building's design. F series locksets offer Schlage's distinctive styling, mechanical integrity, and exceptional value and provide tough reliable performance and enduring style.

Features:

• Hall/Closet (Passage) Function - Both knobs/levers are always unlocked
• Box Pack
• Reversible Handing
• Includes all mounting hardware for easy installation
• Lifetime Mechanical & Finish Warranty

Specifications:

Strike	1-5/8" x 2-1/4" radius corner, full lip, no box
Backset	Fits either 2-3/8" or 2-3/4"
Warranty	Lifetime mechanical and finish warranty
Certifications	ANSI/BHMA A156.2-2011, Grade 2 certified
Keying	Non-keyed lock
Latch	1" x 2-1/4". 1/4" radius corner faceplate, 7/8" housing diameter, 1/2" throw
Material	Brass
Lever Length	3-7/8"
Projection	2-7/16"



Downloads:

• Installation Instruction
