Kwikset - Cove Knob Set - Round Rose - Satin Nickel - Passage - Grade 3

KWS-CV


As the industry leader, Kwikset has provided trusted security for over 70 years and has become synonymous with security, peace of mind, style, and innovation. The attractive, traditional colonial design of the Cove makes a simple yet elegant statement in any home. This Passage knob/lever is best used on interior hall and closet applications where no locking is required. The knob/lever is reversible and mounts on both left and right-handed doors.

• Passage for use on interior doors requiring no locking functionality, such as hallway or closet doors

• Privacy is required for use in interior bedroom and bathroom applications.
• Universal handing; fits both right-handed and left-handed doors.

• Latch has 2 interchangeable faceplates; round corner and square corner

• ANSI/BHMA Grade 3 certified

• Latch has an adjustable backset 2-3/8-in to 2-3/4-in to fit all standard door preparations
• Easily installs in minutes with just a screwdriver

• Lifetime mechanical and finish warranty



Specifications

Function	Passage
Finishes	Satin Nickel
Door Prep	2-1/8"
Backset	Adjustable 2-3⁄8" or 2-3⁄4"
Door Thickness	1-3⁄8" - 1-3⁄4” Doors standard
Door Handing	Reversible
Edge Bore	1"
Cross Bore	2-1/8"
Faceplates	1" x 2-1⁄4" round corner, square corner
Handle Height	2-3/16"
Handle Width	2-3/16"
Handle Projection	2-1/2"

Downloads

• Installation Guide
• Sell Sheet
