Kwikset - 740PML - Pembroke Lever Set - Round Rose - 11P - Venetian Bronze - Entrance - SmartKey Technology - Grade 2
Pembroke Keyed Entry Door Lever Set with Smart Key by Kwikset
Evoking a sense of antiquity, the Pembroke by Kwikset delivers style with the guarantee of solid craftsmanship. This is a Single Cylinder Keyed Entry door lever set which means the lever can be locked and unlocked from the exterior using a key and from the interior using the turn button located on the interior lever.
Features:
- Key it Yourself: Lock is rekeyable by using the included learn tool in less than 30 seconds without removing the lock from the door.
- Fully adjustable latch that fits all standard door preparations (2-3/8" to 2-3/4" backsets)
- ANSI/BHMA Grade 2 Security
- Fully reversible Lever “ Fits both right handed and left handed doors
- Includes Standard Round Corner Strike Plate Part Number 83796 (Strike Plate is on Door Jamb). For Square Corner Strike Plate See Product: Kwikset 83437. For a T-Strike Plate See: Kwikset 83028.
- Evoking a sense of antiquity, the Pembroke delivers style with the guarantee of solid craftsmanship
- Both knobs locked or unlocked by key outside or turn button inside
| Door Prep | Cross Bore 2-1 �8". Edge bore 1". |
| Backset | Adjustable 2-3�8" or 2-3�4". UL functions 2-3�4" standard or 2-3�8" optional. |
| Door Thickness |
1-3�8" - 1-3�4� Doors standard. |
| Cylinder |
SmartKey Security or Pin & Tumbler |
| Faceplates | 1" x 2-1 �4" Specify round corner, square corner or drive-in. |
| Strikes |
2-1 �4� Full lip. Specify round corner or square corner. Other options available. |
| Bolt |
1 �2� Throw |
| ANSI/BHMA |
Grade 2 Certified |
| ADA | 200 and 488 functions satisfies section 4.13.9 ADA requirements. |
| UL | Meets 3-hour fire rating for all UL specific functions. |
Downloads
- Data Sheet
- Installation Guide
- Specifications
