Dahua / Wi-Fi / 4MP / Mini Dome Camera / Fixed / 2.8mm Lens / Outdoor / WDR / IP67 / 30m IR / 5 Year Warranty / DH-IPC-HDBW1435EN-W-S2

DH-IPC-HDBW1435EN-W-S2

• 1/3-in. 4 MP Progressive-scan CMOS Sensor
• 2.4 GHz WiFi (IEEE802.11/b/g/n)
• Smart H.265+ and Smart H.264+ Dual Codec
• Dual-stream Encoding

• 4 MP (2560 × 1440) at 20 fps
• 2.8 mm Fixed Lens
• True Day/Night (ICR)
• Maximum IR Distance 30 m (98 ft)
• IP67 Ingress Protection and IK10 Vandal Resistance
• Five-year Warranty (for products sold through an authorized Dahua Dealer)
• Call 1-800-878-6604 for Dealer Prices!

Technical Specifications

	Camera
Image Sensor	1/3-in. 4 MP Progressive-scan CMOS
Effective Pixels	2560 (H) x 1440 (V)
RAM/ROM	256 MB / 128 MB
Scanning System	Progressive
Electronic Shutter Speed	Auto, Manual, 1/3 s to 1/100,000 s
Minimum Illumination	Color: 0.8872 lux at F2.0 (1/30 s, 80 IRE) Color: 0.936 lux at F2.0 (1/3 s, 80 IRE) B/W: 1.0275 lux at F2.0 (1/30 s, 80 IRE) B/W: 0.1543 lux at F2.0 (1/3 s, 80 IRE) 0 Lux at F2.0 (IR on)
S/N Ratio	More than 51.025 dB
IR Distance	Distance up to 30 m (98.04 ft)
IR On/Off Control	Auto, Manual
IR LEDs	18
	Lens
Lens Type	Fixed
Mount Type	M12
Focal Length	F2.0
Angle of View	Horizontal: 97° Vertical: 52° Diagonal: 116°
Iris Control	Fixed
Close Focus Distance	0.80 (2.60 ft)
DORI¹ Distance	Detect: 56m (183.7 ft) / Observe: 22.4m (73.5 ft) / Recognize: 11.2m (36.7) Identify: 5.6m (18.4 ft)
	Installation Angle
Range	Pan: 0° to 360° Tilt: 0° to 90° Rotation: 0° to 355°
	Video
Compression	Smart H.265+, H.265, Smart H.264+, H.264, H.264H, H.264B, MJPEG
Streaming Capability	Two (2) Streams
Resolution	4 MP (2560 x 1440), 3 MP (2304 x 1296), 1080p (1920 x 1080), 1.3 MP (1280 x 960), 720p (1280 x 720), VGA (640 x 480), 640 x 360, QVGA (320 x 240)
Frame Rate	2560 x 1440 at 20 fps 2304 x 1296 at 30 fps 640 x 480 at 20 fps (Main Stream: 2560 x 1440 at 20 fps) 640 x 480 at 30 fps (Main Stream: 2304 x 1296 at 30 fps)
Bit Rate Control	CBR, VBR
Bit Rate	H.264: 24 kbps to 8192 kbps H.265: 9 kbps to 7424 Kbps
Day/Night	Auto (ICR), Color, B/W
BLC Mode	BLC, HLC, Digital WDR
White Balance	Auto, Natural, Street Lamp, Outdoor, Manual, Regional Custom
Gain Control	Auto, Gain Priority, Shutter Priority, Manual
Noise Reduction	3D DNR
Motion Detection	Off, On (4 Zones, Rectangular)
Region of Interest	Off, On (4 Zones)
Smart IR	Support
Flip	0°, 90°, 180°, 270°
Mirror	Off, On
Privacy Masking	Off, On (4 Areas, Rectangular)
	Network
Ethernet	RJ-45 (10/100 Base-T)
WiFi	2.4 GHz WiFi (IEEE802.11b/g/n)
Protocol	HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP
Interoperability	ONVIF (Profile T, Profile S, Profile G), CGI, SDK, API
Streaming Method	Unicast, Multicast
Maximum User Access	20 Users (Total Bandwidth: 40 Mbps)
Edge Storage	Network Attached Storage (NAS), FTP, SFTP, Micro SD card Slot, maximum 128 GB
Web Viewer	IE 9 and IE 11 and later, Chrome, Firefox
Management Software	DMSS
Mobile Operating System	IOS, Android
	Certifications
Safety	EN 62368-1
Electromagnetic Compatibility (EMC)	CFR 47 FCC Part 15 Subpart B Electromagnetic Compatibility Directive 2014/30/EU Radio Equipment Directive 2014/53/EU
	Electrical
Power Supply	12 VDC ±30%, 1 A
Power Consumption	4.9 W, maximum (12 VDC, IR Full Intensity)
	Environmental
Operating Temperature	–30°C to +50°C (–22° F to +122° F) Less than 95%RH
Storage Temperature	–40°C to +60°C (–40° F to +140° F)
Ingress Protection	IP67
Vandal Resistance	IK10
	Construction
Casing	Metal
Dimensions	ø110.70 mm x 88.70 mm (ø4.36 in. x 3.49 in.)
Net Weight	0.41 kg (0.90 lb)
Gross Weight	0.73 kg (1.61 lb)
