Dahua / 64 Channel / Network Video Decoder / Ultra-HD / 12MP / 12VDC / DH-NVD01054K
DH-NVD01054K
The NVD0105DH is a network video decoder that allows customers to easily route IP video from cameras to a video wall without the need of a PC or NVR. Perfect for small to medium scale deployments where display and control is required.
- Provides Real-time Decoding
- Smart H.265+, H.265, H.264, MPEG4, MJPEG Video Compression
- Ultra-high Decoding Capability, up to 12 MP on Three (3) Channels
- HDMI/VGA Output; HDMI Supports 4K Output
- Supports 1/4/9/16/25/36/64 Split-screen Display
- Audio, Alarm, and Bi-directional Talk
- Become a registered dealer of Dahua
- Call 1-800-878-6604 for Dealer Prices!
Technical Specification
| System | |
| Main Processor | Intel x86 Processor |
| Operating System | Linux |
| Performance | |
| Video Compression | Smart H.265+ H.265, H.264, MPEG4, MJPEG |
| Audio Compression | PCM, G711 |
| Decoding Resolution | 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p, 960H, D1, HD1, 2CIF, CIF, QCIF |
| Video Decoding |
3 channels of 12 MP at 25 fps 4 channels of 8 MP at 30 fps 6 channels of 6 MP at 25 fps 8 channels of 5 MP at 25 fps 9 channels of 4 MP at 25 fps 10 channels of 3 MP at 30 fps 12 channels of 3 MP at 25 fps 16 channels at 1080P 36 channels at 720P 64 channels at D1 |
| Video Output | HDMI or VGA |
| Display Resolution | 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 |
| Audio Output | HDMI |
| Communication Interface | One (1) RJ45 Network Port (10/100/1000 Mbps) Self-adaptive One (1) RS232 Port (DB9) |
| Bi-directional Talk | Input: One (1) Channel, RCA Output: One (1) Channel, RCA (2 Vrms, 10K Ω) |
| Video Input | 2 HDMI, 2 DVI-I |
| Alarms | Input: Four (4) Channels Output: Four (4) Relays (30 VDC 1 A, 125 VAC, 0.5 A) |
| Power, Environment, Construction | |
| Power Supply | 12 VDC, 3.3 A |
| Power Consumption | ≤ 20 W |
| Working Temperature | -10 °C to +55 °C (14 °F to 131 °F) |
| Working Humidity | 10% to 90%, 86 Kpa to 106 Kpa |
| Unit Dimension | 1U, 440.0 mm x 322.80 mm x 44.0 mm (17.32 in. x 12.71 in. x 1.73 in.) |
| Weight | 3.20 kg (7.05 kg) |
Downloads:
