Command Access - PS440B - Power Supply - 4 Amp - 24VDC - Battery Backup

CAT-PS440B

The PS440B power supplies input 110-120VAC and deliver (4) amps @ 24VDC to (4) PTC fused outputs. It also provides (4) solid-state input triggers, protects system relays from shorts, grounds and surges. Its linear design makes it a perfect match for solenoid and motor driven exit devices, electric locks, electric strikes, and mag locks.

Features:

• Built to run up to 4 locks, exit trim & lp motor/solenoid kits
• Robust solid-state outputs - Protects system relays
• Rock-solid board design improves reliability
• Built to last in the USA

• Linear design ensures ample inrush/ hold current for latch retraction
• Door mounted LED Power Indicator
• Interruption free battery back-up
• Easy to remove euro connectors



Specifications:

Input Voltage:	120 VAC, 60 Hz, • Input Fuse: 2 Amp Fuse @ 250VAC
Output Voltage:	4A @ 24VDC • 4 Solid State I/O’s - 1.5A auto resetting fused outputs
Fire Alarm:	Fire alarm link
Electrical:	Temperature range: 0 to 49° C; 32 to 120° F • Maximum humidity: 85%
LED’s:	Red = A/C Power indicator • Green = D/C Output indicator • Orange = Battery Output Indicator
Battery Backup:	Regulated, independent battery charging • Automatic uninterrupted backup circuit • Battery cables included • Requires (2) 12VDC 7AH batteries • Batteries not included
Dimensions:	13” W x 15.5” H x 5” D
knockouts:	1/2” & 3/4”
Hinge-less removable cover:	Cam lock not provided
Operating Voltage:	24 VDC
UL294 (6e) Security Levels:	Destructive Attack: Level I Line Security: Level I Endurance: Level IV Standby Power: Level I
Rated Power:	Class 2 Rated power limited output
Listings:	UL294 6th Edition
Warranty:	3-Year Manufacturer Warranty
