Cal Royal - Single Cylinder Gate Latch - Standard Duty - Less Core - Satin Chrome - Grade 2

Standard Duty Gate Latches for Light Commercial & Residential Applications

Features:

• Conforms with ANSI A 156.2 Series 4000, Standard Duty Grade 2

• Solid brass 6 pin “C” keyway cylinder

• ADA (American Disability Act) Ergonomic Thumbturn

• Cast solid brass housing

• Tapered cylinder guard and metal insert, turns free with any removal attempt

• Meets the Buy American Act

• 2 3/4" MORTISE GATE LATCH

• Adjustable 1 3/8" (35mm) to 1 3/4" (45mm) door thickness.




Specifications:

Collection	Cal-Royal
Function	Single Cylinder Gate Latch Deadlocking latch bolt retracted by key from outside or by thumb turn on inside. Otherwise always locked (2 ¾” backset)
Finish	626 - Satin Chrome
Backset	2-3/4"
Door Thickness	1-3/8" - 2-1/4"
Strike	1 ⅛” X 2 ¾” square corner.
Cylinder	6 pin solid brass "C" keyway standard.
Keyway	KW1
Certification	Conforms with ANSI A 156.2 Series 4000, Standard Duty GRADE 2
