Baldwin - 180MDH - Medina Sectional Handleset - Singl Cyl Deadbolt - Exterior Pull Handle - 11P- Venetian Bronze - SmartKey Technology - Grade 2

BLD-180MDH-LIP-11P-SMT-RCAL

Baldwin 180MDH Medina Single Cylinder Deadbolt Handleset with Pull Handle

Single Cylinder Deadbolt with Pull Handle : Baldwin's single cylinder deadbolts are keyed only on the exterior with an associated thumb turn on the inside that can quickly and easily lock or unlock the mechanism. The handle is exterior pull only

Features:

• Featuring SmartKey Security, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds
• Elegant Low Profile Cylinder
• Architecturally Inspired Design
• ANSI/BHMA Grade 2 Security Features
• Easy to Install
• Adjustable Backset Latch Fits 2-3/8" (60mm) or 2-3/4 (70mm)
• Patented Side Locking Bar Technology Offers Improved Security by Protecting Against Lock Bumping
• There is no interior handle...the lower handle is pull only


Specifications

Configuration	Handleset w/ Deadbolt and Pull Only Handle
Cylinder	Single Cylinder Deadbolt w/ SmartKey Technology
Keyway	Kwikset KW1 - SmartKey
Handing	Reversible
Finish	11P- Venetian Bronze
Latch Faceplate	Round Corner
Center to Center	5.5" in.
Grip Center to Center	8.406 in.
Backset	Adjustable 2-3/8" or 2-3/4"
Cross Bore	2-1/8"
Edge Bore	1"
Door Thickness	1-3/4"
BHMA Certification	Grade 2

Downloads

• Spec Sheet
• Installation Instructions

Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Baldwin directly at 800-566-1986 or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
